Radio | Dual-stream dual-band |
Protocol | Concurrent 802.11a/b/g/n/ac/ax |
Operating Bands | 802.11b/g/n/ac/ax ：2.4G ~ 2.4835GHz 802.11a/n/ac/ax： 5G：5.150～5.350GHz，5.725～5. (country specific) |
Antenna | Internal antennas (2.4G: 4dBi，5G: 6dBi) |
Spatial Streams | 2.4G 2x2MIMO 5G 2x2MIMO |
Max Throughput | Up to 575Mbps at 2.4G Up to 1200Mbps at 5G Totally 1775Mbps per AP |
Modulation | DBPSK/DQPSK/CCK(DSSS)/BPSK/QPSK/16QAM/64QAM/256QAM/1024QAM |
Receive Sensitivity | 11b：-91dBm(1Mbps)，-88dBm(5Mbps)，-85dBm(11Mbps) 11a/g：-89dBm（6Mbps），-80dBm（24Mbps），-76dBm（36Mbps），-71dBm（54Mbps） 11n：-83dBm@MCS0，-65dBm@MCS7，-83dBm@MCS8，-65dBm@MCS15 11ac HT20：-83dBm（MCS0）, -57dBm（MCS9） 11ac HT40：-79dBm（MCS0）, -57dBm（MCS9） 11ac HT80：-76dBm（MCS0）, -51dBm（MCS9） 11ax：HE80：-82dBm（MCS0）, -57dBm（MCS9）,-52dBm（MCS11） |
Maximum Output Power of the Transmitter (Single Stream) | 2.4GHz(2.4~2.4835GHz)：26dBm 5GHz(5.150~5.250GHz,5.725~5.850GHz)：25dBm （country-specific，comply with local laws） |
Adjustable Power | 1dBm |
Dimensions | 298mm×298mm×65mm (excluding mounting kits) |
Weight | ≤1.35kg (excluding mounting kits) |
Service Ports | 1 10/100/1000 Base-T Ethernet port supports PoE IN； 1 100/1000 Base-X SFP Port |
Management Port | N/A |
LED Indicator | Single indicator (Blue light) |
Power Supply | 802.3af/802.3 at PoE |
Power Consumption | ≤17W |
Bluetooth | Support |
Environment | Operating Temperature：-40°C～65°C |
Installation | Ceiling/Wall-Mountable |
Safety Standard | GB4943、IEC 60950-1 |
EMC Standard | GB9254、EN301 489，EN50155：EN50121 |
Vibration Standard | IEC61373 |
Radio Standard | EN300 328，EN301 893 |
MTBF | >400000H |
WLAN | Maximum number of clients: 512 |
Roaming | Support layer 2 and layer 3 roaming |
Security | Support PSK authentication |
Routing | Support static IP address, DHCP, PPPoE Dial |
Management and Maintenance | Support unified networking of all network equipment Support local or remote management with Ruijie Cloud APP Support local management with web Support remote management with Ruijie Noc Cloud platform |
Platform Management Features | Automatic RF adjustment via the platform |
